JL-45
JIANLAI
Product Description
JL-45 floor spring capacity is 100kg. It's used with frame/frameless glass door, aluminum door, wood door and so on. If you install in wood door and aluminum door, we will send the accessories with the hydraulic floor spring. The door width is about 1000mm. The stainless steel floor hinge has two adjustable speed to control the speed.
Our glass door floor spring can run 50,000 cycle times. We ensure 5 years warranty of our stainless steel floor spring. With high strength and leak prevent configuration, our floor spring extend the life times.
We also have patch fitting, glass door lock, shower enclosure kits and handle series. You can find all glass hardware products in our company.
Product Characteristics
Single Cylinder
Heavy Duty
Easy to Install
50,000 Cycle Times
5 Years Warranty
OEM/ODM
One Stop Solution of Glass Hardware Products
Data Sheet
Model No. | JL-45 |
Type | floor spring |
Cover Plate Material | stainless steel |
Cover Plate Size | 266*122mm |
Cover Plate Thickness | 1.0mm/1.2mm |
Cement Box Size | 255*103*52mm |
Body Material | casting iron |
Finish | satin/mirror/matt black/gold |
Capacity | 100kg |
Opening Angle | 90°and 135°stop-device |
Door Width | 1300mm |
Wood Door Accessories | optional |
Logo | optional |
Packing | each floor spring pack in one box. 4pcs floor springs pack in one carton. |
Production Time | 25-35 days |
Sample | available |
Service | OEM/ODM |
